2017 Ford F-750 Regular Cab DRW RWD Brown Industries Box Truck
Stock #W0286X
Vehicle Notes
This one-owner medium-duty truck is built to handle demanding commercial tasks with ease. Featuring a large 18-foot box and backed by Fords reliable F…
Read More…
Read More…
Chassis Details
Mileage
18,472
Stock Number
W0286X
Stock Type
Used
Year
2017
Make
Ford
Model
F-750
Class
7
Drivetrain
RWD
Cab Type
Regular
Vehicle Trim
Base
Vehicle Body
2D Standard Cab
Interior Color
Gray
Seating Capacity
3
Exterior Color Description
White
Engine Cylinder Count
8
Transmission Type
Automatic
Rear Wheels
Dual
Fuel Type
Diesel
Engine Make
Ford
Engine Size (L)
6.7
Horsepower
330
Brake Type
Air
Vehicle Options
- 2 Speakers
- AM/FM radio
- Radio: AM/FM Stereo w/Aux Audio Input Jack & Clock
- Air Conditioning
- Power steering
- Steering Column - Tilt
- Steering Wheel - Black PVC w/Integral Cruise Control Switches
- ABS brakes
- Bumper, Front - Black, Full Width
- Speed control
- Dual rear wheels
- Engine Exhaust Brake
- Body Builder Wiring - At Back of Cab, Combined
- Lights - Roof Marker/Clearance - Amber Lenses, 5 Lights
- Painted Grille - Plastic
- 30/0/30 Fixed Driver & Fixed Passenger w/Consolette - Vinyl
- Floor Covering - Black Vinyl
- Four Body Builder Switches - Mounted in Center Instrument Panel
- Front reading lights
- Intelligent Oil Life Monitor
- Manual Regen Initiation - Driver Interface in Message Center
- Passenger seat mounted armrest
- Passenger vanity mirror
- Tachometer
- Tilt steering wheel
- Trip computer
- Driver's Seat Mounted Armrest
- Tow Hooks, Front (2) - Frame-Mounted, Painted Black
- Wheel Seals, Front - Oil lubricated, SKF ScotSeal PlusXL Seals
- Wheel Seals, Rear - Oil lubricated, SKF ScotSeal PlusXL Seals
- Variably intermittent wipers
- View All
Body Details
Manufacturer
Body Type
Box Truck
Liftgate Manufacturer
PALFINGER
Liftgate Model
ILT-35-PD
Liftgate Type
Tuck Away
Liftgate Description
92" x 86"
Liftgate Material
Aluminum
Liftgate Capacity
3500 lb
Body Material
Aluminum
Body Height
103
Body Width
102
Body Length
18'
Body Inside Height
97
Body Inside Length
17'
Door Manufacturer
Whiting
Door Type
Roll Up
Door Material
Composite
Door Height
91.75"
Door Width
84"
Floor Thickness
1-1/8" Laminated Oak
Side Description
.040 Aluminum Panels| Plywood Lining
Cargo Control Type
E-Track
Cargo Control Description
Both Sides
Cargo Control Location
Side
Has Mud Flaps
Yes
Aluminum Dry Freight Features
- Rear Frame of 12 ga. Stainless Steel with Internal L Gussets at All Corners
- 12" Extruded .090" Aluminum Radius Front with 7 Vertical Z-posts and HD Cast Aluminum Corner Caps
- Translucent .060" Fiberglass Roof with Roof Bows on 24" Centers
- 4" Long Sills
- 60,000 psi, 3" Steel I-Beam Cross Sills on 12" Centers
- Side Panels are .040" Prepainted Aluminum with Baked Acrylic Finish and Contant 2" Rivet Pattern
- Galvanized Steel Z-Posts on 16" Centers
- Inset Micro LED Clearance Lights
- Sealed Harness with Return Ground Wire
- Composite Roll Up Rear Door with Dual Springs and 2" Rollers
Upfit Notes
- 1 MODEL: 917 XC 18' Brown Cargo Van
- 2 LENGTH: Length reduced for 17' overall inside body length
- 3 CONSTRUCTION: Sheet and post with pre-painted white, smooth .040" aluminum panels riveted to galvanized posts on constant 2' centers
- 4 FRONT: 12· extruded .090" aluminum upper front radius with heavy duty front upper comer aluminum castings and 5' extruded .090" aluminum
- comer posts
- 5 ROOF: One-piece .060" translucent fiberglass roof, with anti-snag roof bows on 24' centers
- 6 WIDTH: 102" overall wide body
- 7 HEIGHT: 97-1/2" high inside, 103-1/4" high outside
- 8 REAR DOOR: WMing Premium composite rol-up rear door, with dual spring operator and 2' rolers, 94-W x 91-3/4'H opening
- 9 REAR FRAME: 12 gauge stainless steel with internal 'L • gussets at all four corners and external rain gutter
- 10 GRAB HANDLES: 24' stainless steel, one each rear post
- 11 UNDERSTRUCTURE: 3" hi-tens~e I-beam cross sills on 12· centers, with 2 extra sills at rear on 6' centers. 4' hi-tensile I-beam long sills,
- reinforced bottom plate.
- 12 FLOOR: 1-1/8" domestic laminated oak fastened with (2) 5/16" screws per board per sil, undercoated
- 13 THRESHOLD PLATE: 24" x fuH-width, 14 ga. steel treadplate threshold over floor at rear
- 14 INTERIOR LINER: A-C grade 1/2" plywood liner, lull height, front
- 15 INTERIOR LINER: A-C grade 3/8' plywood liner, full height, sides
- 16 BULKHEAD PLATE: 20• x 4', 10 ga. smooth steel bulkhead angle instaUed at front, fastened under floor and under Uner
- 17 WEARBAND: 12" high, 14 ga. smooth steel wearband, sides and front
- 18 LOGISTIC TRACK: 1 row "E" track each side, recessed in liner at 24" C/L above Hoor
- 19 LOGISTIC BARS: 2 ea. heavy duty aluminum locking bar for "E" track, for 102" wide body
- 20 LOGISTIC TRACK: 1 row vertical "E" track each side of body, centered at 54' from inside front, recessed in plywood liner, mounted to 2 extra
- body side posts each side
- 21 CARGO NET: US Cargo Control CN-250 82" x 82' cargo net with "E' type fittings and ratchets
- 22 INTERIOR LIGHTING: 1 ea. LED domelight, wired to switch in cab with indicator light
- 23 LIFTGATE: Palflnger Model ILT-35-PO Folding Liftgate, 3,500 lbs. capacity, 62' x 86' extruded aluminum platform, level ride platform with Hush
- hinges, power down. hydraulic cylinder locks, cab shut off switch, 150 amp resettable circuit breaker, bushings and grease zerlls, pre-mounted/
- pre-filled thermo protected power pack, pre-assembled frame and platform, pre-assembled 3-piecerear impact guard, snubber kit, low voltage /
- high amp thermal motor protection, dual platform torsion assist, 102• wide bed extension, 28' x 3/16" heavy duty bolt-on 2-step dock bumpers
- with 24' rubber dock pads, galvanized frame bed extention and dock bumpers/ steps, complete and installed
- 24 REQUIRED LIGHTING: Per FMVSS 108. Clearance lights to be Hush mounted LED with retum ground wire and sealed harness
- 25 MUD FLAPS: Anti-sail mud flaps instaHed
- 26 FOB - Lawrence, KS, mounted on your chassis
Body Installed by
Brown Industries
807 E 29th Street
St. Lawrence, KS 66046
